A2A | A4A | A6A | A8A | |
---|---|---|---|---|
Channels | 7ch | 7ch | 9ch | 11ch |
Rated Output Power (20Hz-20kHz, 2ch driven) |
100W | 110W | 150W | 150W |
Zone | Zone2 | Zone2 | Zone3 | Zone3 |
HDMI in/out | 7/1 | 7/3 | 7/3 | 7/3 |
8K60Hz/4K120Hz, HDR10+ (via firmware update) |
● (8K60B, 4K120AB) |
● | ● | ● |
Dolby Atmos w/Height Virturalizer | ● (via firmware update) |
● | ● | ● |
SURROUND:AI | ─ | ● | ● | ● |
Wireless Rear Speaker Capability | ● | ● | ● | ● |
YPAO | ● (R.S.C/Multi-point) |
● (3D/High Precision EQ/ R.S.C/Multi-point) |
● (3D/High Precision EQ/ R.S.C/Multi-point) |
● (3D/High Precision EQ/ R.S.C/Multi-point) |
Detailed Comparison
RX-A8A | RX-A6A | RX-A4A | RX-A2A |
---|
RX-A8A |
RX-A6A |
RX-A4A |
RX-A2A |
||
---|---|---|---|---|---|
AV Receiver | |||||
Amplifier Section | Channels | 11.2 | 9.2 | 7.2 | 7.2 |
Rated Output Power (20Hz-20kHz, 2ch driven) | 150 W (8 ohms, 0.06% THD) | 150 W (8 ohms, 0.06% THD) | 110 W (8 ohms, 0.06% THD) | 100 W (8 ohms, 0.06% THD) | |
High Slew Rate Amplifier | Yes | Yes | Yes | Yes | |
Surround Sound Processing | Surround:AI | Yes | Yes | Yes | N/A |
Cinema DSP | Yes (HD3) | Yes (HD3) | Yes (HD3) | Yes | |
DSP Programs | 24 | 24 | 24 | 17 | |
Dialog Level Adjustment | Yes | Yes | Yes | Yes | |
Virtual Presence Speaker | Yes | Yes | Yes | Yes | |
Virtual Surround Back Speaker | Yes | Yes | Yes | Yes | |
Dialogue Lift | Yes | Yes | Yes | Yes | |
SILENT Cinema / Virtual Cinema DSP | Yes | Yes | Yes | Yes | |
Dolby Atmos | Yes | Yes | Yes | Yes | |
Dolby Atmos Height Virtualization | Yes | Yes | Yes | Yes | |
Dolby TrueHD | Yes | Yes | Yes | Yes | |
Dolby Digital Plus | Yes | Yes | Yes | Yes | |
Dolby Surround | Yes | Yes | Yes | Yes | |
DTS:X | Yes | Yes | Yes | Yes | |
DTS-HD Master Audio | Yes | Yes | Yes | Yes | |
Auro 3D | Yes (via firmware update) | Yes (via firmware update) | N/A | N/A | |
Audio Features | File Format | MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz | MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz | MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz | MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz |
Pure Direct | Yes | Yes | Yes | Yes | |
Compressed Music Enhancer | Yes | Yes | Yes | Yes | |
High-resolution Music Enhancer | Yes | Yes | Yes | N/A | |
YPAO Multipoint Measurement | Yes with R.S.C. (Reflected Sound Control), 3D, 64-bit High Precision EQ Calculation, Low Frequency mode and Angle Measurement | Yes with R.S.C. (Reflected Sound Control), 3D, 64-bit High Precision EQ Calculation, Low Frequency mode and Angle Measurement | Yes with R.S.C. (Reflected Sound Control), 3D, 64-bit High Precision EQ Calculation, Low Frequency mode and Angle Measurement | Yes with R.S.C. (Reflected Sound Control) | |
YPAO Volume | Yes | Yes | Yes | Yes | |
Adaptive DRC (Dynamic Range Control) | Yes | Yes | Yes | Yes | |
Initial Volume and Maximum Volume Setting | Yes | Yes | Yes | Yes | |
A.R.T. Wedge | Yes | Yes | Yes | Yes | |
Bi-amp Capability | Yes | Yes | Yes | Yes | |
Audio Delay | Yes (0-500 ms) | Yes (0-500 ms) | Yes (0-500 ms) | Yes (0-500 ms) | |
DA Converter | 384 kHz / 32-bit ESS Hyperstream DAC ES9026PRO x2 | 384 kHz / 32-bit ESS Hyperstream DAC ES9026PRO x1 ES9007S x1 | 384 kHz / 32-bit ESS Hyperstream DAC ES9007S | 384 kHz / 32-bit BB PCM5102A | |
Video Features | HDMI eARC | Yes | Yes | Yes | Yes |
HDMI Audio Return Channel | Yes | Yes | Yes | Yes | |
HDMI Pass-through | 4K120AB*, 8K60AB* and 4K60 (*via future update) | 4K120AB*, 8K60AB* and 4K60 (*via future update) | 4K120AB*, 8K60AB* and 4K60 (*via future update) | 4K120AB*, 8K60B* and 4K60 (*via future update) | |
HDMI Upscaling | Yes, up to 8K (via firmware update) | Yes, up to 8K (via firmware update) | Yes, up to 8K (via firmware update) | Yes up to 4K | |
HDMI Up-conversion | Yes (Analog to HDMI) | Yes (Analog to HDMI) | N/A | N/A | |
Dolby Vision | Yes | Yes | Yes | Yes | |
HDR 10+ | Yes (via firmware update) | Yes (via firmware update) | Yes (via firmware update) | Yes (via future update) | |
VRR/ALLM/QMS/QFT | Yes (via firmware update) | Yes (via firmware update) | Yes (via firmware update) | Yes (via future update) | |
Video Adjustment | Yes | Yes | N/A | N/A | |
Connectivity | MusicCast Surround | Yes | Yes | Yes | Yes |
Wi-Fi | Yes (2.4 / 5 GHz) | Yes (2.4 / 5 GHz) | Yes (2.4 / 5 GHz) | Yes (2.4 / 5 GHz) | |
AirPlay 2 | Yes | Yes | Yes | Yes | |
Bluetooth | Yes (SBC / AAC) | Yes (SBC / AAC) | Yes (SBC / AAC) | Yes (SBC / AAC) | |
Phono Input | Yes | Yes | Yes | Yes | |
XLR Terminal | Yes | Yes | N/A | N/A | |
Component Video Input/Output | 1 / 0 | 1 / 0 | N/A | N/A | |
Extensive Connections | HDMI Input/Output | 7 / 3 (HDMI 2.1 / HDCP 2.3) | 7 / 3 (HDMI 2.1 / HDCP 2.3) | 7 / 3 (HDMI 2.1 / HDCP 2.3) | 7 / 1 |
HDMI CEC | Yes | Yes | Yes | Yes | |
USB Input | Yes | Yes | Yes | Yes | |
Network Port | Yes | Yes | Yes | Yes | |
Front AV Input | USB | USB | USB | USB | |
Digital Audio Input / Output: Optical | 3 / 0 | 3 / 0 | 2 / 0 | 1 / 0 | |
Digital Audio Input / Output: Coaxial | 2 / 0 | 2 / 0 | 1 / 0 | 1 / 0 | |
Analog Audio Input / Output | 6 / 0 | 6 / 0 | 4 / 0 | 4 / 0 | |
Composite Video Input / Output | 2 / 0 | 2 / 0 | N/A | N/A | |
Preout | 11.2-ch | 11.2-ch | 7.2-ch | 2.2-ch | |
Headphone Output | 1 | 1 | 1 | 1 | |
Tuner Section | FM / AM Tuner | Yes | Yes | Yes | Yes |
User Interface | On-Screen Display | Graphical User Interface | Graphical User Interface | Graphical User Interface | Graphical User Interface |
SCENE | SCENE PLUS (8 sets) | SCENE PLUS (8 sets) | SCENE PLUS (8 sets) | Yes (8 sets) | |
App Control | Yes (iPhone / iPad / Android phone / tablet) | Yes (iPhone / iPad / Android phone / tablet) | Yes (iPhone / iPad / Android phone / tablet) | Yes (iPhone / iPad / Android phone / tablet) | |
Web Browser Control | Yes | Yes | Yes | Yes | |
Remote Control Unit | Yes | Yes | Yes | Yes | |
Zone Control | Zone 2 Audio Output | Preout / HDMI | Preout / HDMI | Preout / HDMI | Preout |
Zone 3 Audio Output | Preout | Preout | N/A | N/A | |
Zone 4 Audio Output | HDMI | HDMI | N/A | N/A | |
Powered Zone | Zone 2 / 3 | Zone 2 / 3 | Zone 2 | Zone 2 | |
Zone Video Output | HDMI | HDMI | HDMI | N/A | |
Zone B Output | HDMI | HDMI | N/A | N/A | |
Zone GUI | Yes | Yes | N/A | N/A | |
RS-232C Interface | N/A | N/A | N/A | N/A | |
+12V Trigger Output | 2 | 2 | 2 | 1 | |
Remote (IR) Input/Output | 1 / 1 | 1 / 1 | 1 / 1 | 1 / 1 | |
Party Mode | Yes | Yes | Yes | Yes | |
General | Standby Power Consumption (IR only) | <0.4 W | <0.4 W | <0.4 W | 0.1 W |
Auto Power Standby | Yes | Yes | Yes | Yes | |
ECO Mode | Yes | Yes | Yes | Yes | |
Dimensions (W x H x D) | 17-1/8" x 7-1/2" x 18-3/4" (with antenna up:17-1/8" x 10-5/8" x 18-3/4") | 17-1/8" x 7-1/2" x 17-3/8" (with antenna up:17-1/8" x 10-5/8" x 17-3/8") | 17-1/8" x 7-1/2" x 17-3/8" (with antenna up:17-1/8" x 10-5/8" x 17-3/8") | 17-1/8" x 6-3/4" x 14-5/8" (with antenna up:17-1/8" x 9-5/8" x 14-5/8") | |
Weight | 47.2 lbs. | 41.2 lbs. | 35.7 lbs. | 22.5 lbs. |
