AVR-X6800H

8K video and 3D audio experience from an 11.4 channel receiver.

Designed and manufactured in Japan, the AVR-X6800H drives 11.4 channels of amplification for an upscaled experience. With Dolby Atmos and DTS:X, plus IMAX Enhanced and Auro 3D, the AVR-X6800H envelops larger living spaces in breathtaking 3D audio. With HEOS® Built-in, wirelessly stream your favorite music.

• 11.4 channels
• 140W per channel
• 8K Ultra HD
• 3D Audio
• HEOS® Built-in
• Seven HDMI Inputs

The next level in home theater

Maximize your entertainment with a full suite of audio and video technologies plus smart features.

Engineered for excellence

Enveloping 3D audio

Feel like you're in the center of the action with enveloping 3D sound.

Expert ready

Take advantage of the wide variety of configuration options to best fit your space.

Denon craftsmanship

Designed and manufactured at Denon facilities in Japan to meet our highest standards.

Discover an uncompromising home theater AV receiver

Optimize for your room

Enhance performance with room correction options from Audyssey (installed) or Dirac Live® Room Correction and Dirac Live® Bass Control (optional).

Powerful 11-channel amplifier

Featuring a sophisticated power amplifier design, the AVR-X6800H delivers high-power performance at 140 watts per channel (8 Ohms, 20 Hz–20 kHz, THD: 0.05%, 2 ch. driven) to ensure a dynamic and precise entertainment experience.

3D audio experience

Get enveloped in sound with Dolby Atmos®, DTS:X®, IMAX Enhanced and Auro 3D, along with Dolby Surround, DTS Neural:X, and Auro-Matic upmixer to optimize legacy content.

Configuration flexibility

AVR-X6800H offers many setup options and flexibility to adjust your home theater to meet your needs. Supports 13.4 channel processing capability, [Pre-Elevated shot of the back] Amplifier mode, and optional Dirac Live upgradability (with fee).

Advanced 8K home theater

8K video is supported on all seven HDMI inputs and two of the three outputs. With HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR pass-through, there's no need to worry about video compatibility or picture quality.

HEOS® Built-in technology

Stream music wirelessly from a variety of free and premium streaming services. Share content to HEOS devices, like Denon Home speakers, in other rooms.

Number of Power Amps 11
Power Output
140 watts per channel
(8 ohm, 20Hz - 20kHz,
 0.05% 2ch Drive)
175 watts per channel
(6 ohm, 1kHz, 0.7% 2ch Drive)
250 watts per channel
(6 ohm, 1kHz, 10% 1ch Drive)
Other
Auto Speaker Setup
by Microphone
Audyssey MultEQ XT32
Dirac Live (upgrade)
Front Display 2-Line FLD
GUI Languages English, Spanish, French

General
System Remote Control RC-1256
Power Consumption in W 750W
Power Consumption No-Sound
(ECO on/off) in W 65W/110W
Standby Consumption in W 0.1W
CEC Standby Consumption in W 0.5W
Network Standby
Consumption in W Less than 2.0W
Maximum Dimensions
Antenna, Horizontal: 17.1 × 15.3 × 6.6 (W × D × H) in inches
Antenna, Vertical: 17.1 × 15.3 × 9.3 (W × D × H) in inches
w/o Antenna: 17.1 × 14.9 × 6.6 (W × D × H) in inches
Weight in lbs 34.4 lbs
Weight in lbs (Packaging) 40.1 lbs

Inputs/Outputs
VIDEO
HDMI In/Out 7/3
AUDIO
Analog In/Out 6/0
Phono (MM) In Yes
Digital In: Optical / Coaxial 2 / 2
Multi-Room Out: Analog / Digital 2 / 0
Multichannel Pre-Out Yes (13.4)
Subwoofer Out 4 (independent)
Other
Number of Speaker Terminals 13
Speaker A/B Assignable
Bi-Amp Drive Assignable
Multi-Room Speaker Terminal Assignable
