Rotel RA-04

Integrated Amplifier

For great sound, nothing more, nothing less, the RA-04 is reference. It offers identical performance to the RA-05; the only difference is the RA-04 does not include remote control operation. What it does include is Rotel’s Balanced Design Concept in practice, in the form of high-performance parts and finely honed sound.

Specifications
Power output: 40 watts per channel into 8Ω (stereo)
Frequency response: 10Hz to 40kHz
Total harmonic distortion: 0.03%
Damping factor: 180
Input sensitivity: 2.5mV (MM), 150mV (line)
Signal to noise ratio: 80dB (MM), 100dB (line)
Output: 1V (Pre out)
Speaker load impedance: 4Ω (minimum)
Dimensions: 437 x 72 x 342mm
Weight: 5.9kg
