Pro Av VA1000 Headphone & Integrated Tube Amplifier

Pro Av VA1000  Headphone & Integrated Tube Amplifier

Highlights :
It use the best Ultra-linear Push-pull amplifier circuit
Preamplifier use SRPP amplification circuit and Nagao-type inverter circuit, make it let the audio frequency wide, distortion is small.
headphone amplification part

Features :
It use the best Ultralinear Push-pull amplifier circuit, and It uses the latest improved exports version famous vacuum tube 5881A as the power amplifier
Preamplifier use SRPP amplification circuit and Nagao-type inverter circuit, make it let the audio frequency wide, distortion is little.
The output transformer use Japanese audio special stalloy (thickness is 0.35mm) and high strength enamel-insulated wire. It used special coiling process, let the audio frequency wide, to ensure timbre of the trebles, mediant and bass are nice, transparent and powerful.
This amplifier is made with foreign country’s famous factory audio special Enthusiast electrolytic capacitor, nonpolarity capacitor (MKP) and high quality metallic resistance.
Main sound channel is made with imported special sound volume Potentiometers.
This amplifier can direct use earphone.


Specifications产品规格：

Output power:21+21W RMS (8Ω)
Distortion: 5%
Signal noise ratio (SNR):≥78dB(A)
Frequency Response::5Hz-79Khz (-2dB)
Input sensitivity :≤190mV
Input Impedance:≥20KΩ
Output Impedance: 4Ω or 8Ω
Earphone output: VAILABLE
Vacuum tubes: 5881A x4 , 6N1 x4 , 6E2(electro-optical tube) x2
Volume:(L)340mm X (W)360mm X (H)160mm
Gross Weight: about 14kg
