Pro Av CS-60 6'' 6W Ceiling Speaker ( Pair )

Pro Av CS-60 6'' 6W Ceiling Speaker is a well-engineered 6-inch ceiling speaker designed for background music and public address applications in both commercial and residential environments. Ideal for spaces such as shopping malls, hospitals, offices, schools, meeting rooms, and even home audio systems, it offers a clean, minimalist design that blends seamlessly into modern ceilings.

With a wide frequency response of 100Hz to 15kHz and a high sensitivity of 93±3dB, the CS-60 delivers clear and natural sound, making it perfect for background music playback and voice announcements. The speaker operates on a 100V constant voltage system with selectable 3W or 6W power settings to suit different space and volume requirements. Constructed with a durable ABS front panel and a white aluminum grille (RAL9016), it is both robust and aesthetically pleasing.

Key Features:

• Frequency Response: 100Hz – 15kHz for smooth and natural sound reproduction

• High Sensitivity: 93±3dB, ensuring wide coverage

• Power Options: 3W / 6W selectable for flexible audio zoning

• Easy Installation: φ170mm cut-out with spring clip mounting

• Front Panel: ABS (adult white), Grille: White aluminum (RAL9016)

• Impedance: 7.2Ω

• Ideal for background music and public announcements

Specifications –

Pro Av CS-60 6'' 6W Ceiling Speaker

Frequency Response 100Hz – 15kHz

SPL (1W/1m) 93±3dB

Rated Power 6W

Power Taps 3W / 6W

Input Voltage 100V

Cut-out Size Ø170mm

Product Dimensions Ø186 × 71mm

Baffle Material ABS (Adult White)

Grill White Aluminum Grill (RAL9016)

Speaker Size 6 inches

Product Color White

Net Weight (each) 0.76kg

Packaging Size 52 × 41 × 23 cm

Speaker Driver Specifications

Item Specification

Voice Coil PSV20.4 × Ø0.12” × 2T

Impedance 7.2Ω

Cone Material Paper

Magnet Type Ferrite Magnet (153g)

Magnet Size Ø70 × 32 × 10mm (Y25)

Frame Material ABS

Surround Material Cloth

Dust Cap Paper

Net Driver Weight 520g
