Onkyo TX-L50 5.1Ch Atmos Network AV Receiver (PL)

TX-L50

5.1-Channel Network A/V Receiver

The Smart Choice for Stress-free Surround-Sound

There’s a path to immersive surround-sound that won’t result in a messy living space, and it’s called the TX-L50. Slim, smart, and ready to fit into your existing furniture, the receiver cleans up cable clutter by integrating your players into the TV via one HDMI®, and by letting you cast music wirelessly from smartphone apps in seconds. Lush, cohesive sound transforms daily entertainment, from TV shows to LP records, thanks to responsive six-channel amplification. With the addition of a compact speaker set, cinema magic is on tap with simple playback control to help to melt stress away.

Unlock Dolby Atmos® and DTS:X® Playback

Object-based mixing lets sounds play through any speaker independently. Effects move above and around you as in real life. Enjoy movies and games with 3.1.2-channel Dolby Atmos* sound, and DTS:X through any speaker layout, and discover a new sonic dimension.

* Enabled with firmware update.

Music Made Easy with Chromecast built-in* and Google Assistant**

Stream any music from your smartphone, laptop, or PC to the TX-L50 with ease. Control playback with Chromecast-enabled apps you know and love from your iPhone, iPad, Android™ phone or tablet, Mac or Windows® laptop, or Chromebook. Control with your voice in conjunction with speakers featuring the Google Assistant.

* Enabled with firmware update.**Availability of source depends on region

・Google and related marks and logos are trademarks of Google LLC.
・The Google Assistant is not available in certain languages and countries. Requires Internet connection. Availability of services varies by country and language. Subscriptions for services may be required.

Ready for DTS Play-Fi®* Multi-room Audio

DTS Play-Fi allows you to enjoy high-quality music from connected online services, networked media servers, and your device library over Wi-Fi® to any number of compatible products using the Onkyo Music Control App for iPad, iPhone, and Android™ smartphones/tablets. DTS Play-Fi can synchronize the music in every room. Each member of your family can use their own device to listen to their own music in their room or group of rooms. DTS Play-Fi lets you easily structure a comprehensive multi-room ecosystem that satisfies virtually any need. For more information, visit www.play-fi.com.

* Enabled with a firmware update.

Supports TIDAL*, Spotify®, Deezer(Deezer HiFi)*, and TuneIn

The TX-L50 supports a variety of streaming services, giving you immediate access to a massive selection of music with easy song selection and control via smartphone apps.

* Service enabled via firmware update.

Stream and Control with Intuitive Remote App

The ability to control music from anywhere in your home is right in your pocket: our free Onkyo Controller app gives quick access to inbuilt streaming services and lets you control playback from anywhere within range of the home network.

FlareConnect™ Wireless Multi-room Audio

FlareConnect* shares audio from network and external audio input sources between compatible components. Enjoy effortless multi-room playback of LP records, CDs, network music services, and more with supported components and speaker systems. Music selection, speaker grouping, and playback management across the home are built into the Onkyo Controller** app.
For external input availability, click here

* Sharing audio from external inputs is enabled with a firmware update. External audio inputs supporting FlareConnect may differ depending on model. Please consult individual product specification for more information. ** Download free from the App Store or Google Play.

AccuEQ Room Acoustic Calibration

In moments, AccuEQ measures and analyzes sound output from your speaker layout and corrects the response for beautifully clear and cohesive surround-sound in your listening space, no matter the shape or size.

Wi-Fi®, AirPlay, and Bluetooth® Technology

Dual-band 5 GHz/2.4 GHz Wi-Fi assures a stable connection so you can stream over AirPlay and the local network. Bluetooth wireless technology provides a quick and simple streaming from your choice of app and device.

Surround Enhancer* Mode

Based on technology developed by Dolby Laboratories, Inc., Surround Enhancer Mode augments the object-based soundfield with virtual channels that emulate a 5.1.2-channel Dolby Atmos experience as delivered by a comparable 7.1-channel receiver. With Surround Enhancer Mode, you can enjoy a 5.1.2-channel 3D soundfield easily without need of rear speakers.

* Enabled with firmware update.

Delivering Content to UltraHD TVs

Up to four media players can be connected to the receiver via HDCP 2.2-compliant HDMI® terminals, sending 4K/60p video to the latest displays via a single cable. Signals encoded with BT.2020, 4:4:4 color space, and HDR are passed through to the display for truly stunning pictures.

Delivering Content to UltraHD TVs

Up to four media players can be connected to the receiver via HDCP 2.2-compliant HDMI® terminals, sending 4K/60p video to the latest displays via a single cable. Signals encoded with BT.2020, 4:4:4 color space, and HDR are passed through to the display for truly stunning pictures.

Surround Sound for Films and Gaming

The TX-L50 decodes multichannel Dolby® TrueHD and DTS-HD Master Audio™ so you get an authentic surround-sound experience as the director intended. Various listening modes are included to optimize different content.

General Specifications
Amplifier (Audio) section
Rated Output Power (IEC)
6 ch k 80 W at 4 ohms, 1 kHz, 1 ch driven of 1% THD
Input Sensitivity and Impedance (1 kHz 80 W/4 Ω)
200 mV/47 kΩ (LINE (Unbalance))
6.0 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
1 V/470 Ω (SUBWOOFER PRE OUT)
Phono Overload
30 mV (MM 1 kHz 1%)
Frequency Response
10 Hz - 40 kHz/i1 dB, j3 dB
Tone Control Characteristics
n10 dB, 90 Hz (BASS)
n10 dB, 7.5 kHz (TREBLE)
Signal to Noise Ratio
80 dB (IHF-A, LINE IN, SP OUT)
70 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance
4 Ω - 8 Ω
Headphone Output Impedance
102 Ω
Headphone Rated Output
85 mW (32 Ω, 1 kHz, 10% THD)

Tuner Section
FM Tuning Frequency Range
87.5 MHz - 108.0 MHz, RDS
Preset Channel
40

Network Section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
IEEE 802.11 a/b/g/n standard
(Wi-Fi® standard)
5 GHz/2.4 GHz band

BLUETOOTH Section
Communication system
BLUETOOTH Specification version 4.1+LE
Frequency band
2.4 GHz band
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
A2DP 1.2
AVRCP 1.3
HOGP-Host (Client)
HOGP-HID Device (Server)
HID Service (HIDS)
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 15 m ( ＊ )
＊ The actual range will vary depending on factors such as
obstacles between devices, magnetic fields around a microwave
oven, static electricity, cordless phone, reception sensitivity,
antenna’s performance, operating system, software application,
etc.

General
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption
60 W
0.38 W (Stand-by)
16 W (No-sound)
2 W (HDMI Standby Through)
2.9 W (Network Standby)
Dimensions (W k H k D)
435 mm k 70 mm k 325.5 mm
17-1/8" k 2-3/4" k 12-13/16"
Weight
4 kg (8.8 lbs)

HDMI
Input
IN1 (BD/DVD, HDCP2.2), IN2 (CBL/SAT, HDCP2.2), IN3
(STRM BOX, HDCP2.2), IN4 (GAME, HDCP2.2)
Output
OUT (HDCP2.2)
Supported
Deep Color, x.v.ColorTM, LipSync, Audio Return Channel,
3D, 4K 60Hz, CEC, Extended Colorimetry (sYCC601,
Adobe RGB, Adobe YCC601), Content Type, HDR
Audio Format
Dolby TrueHD, Dolby Digital, Dolby Digital Plus, Dolby
Atmos (to be supported in a future update), DTS, DTS:X
(to be supported in a future update), DTS-HD Master
Audio, DTS-HD High Resolution Audio, DTS 96/24, DTSHD Express, DSD, PCM
Maximum Video Resolution
4k 60 Hz (YCbCr 4:4:4)

Audio Inputs
Digital
OPTICAL (TV)
COAXIAL (CD)
Analog
1 (BD/DVD), 2 (CBL/SAT), PHONO (designated)

Audio Outputs
Analog
SUBWOOFER PRE OUT
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R, SUBWOOFER
Phones
PHONES (Front, φ3.5 mm)
