Moon ACE All-in-One Music Player (PL)

ACE All-in-One Music Player

The ACE acts as the heart and soul of a high-performance audio set-up and the onboard MiND2 (MOON intelligent Network Device) module allows simple operation via the MOON MiND Controller app or remote handset. The app provides a full graphic interface allowing effortless access to streaming services and your digital music library.

Design features

• 3 line-level inputs including a front-mounted 1/8” mini-jack for personal media players.
• Headphone output on 1/4” jack located on the front panel.
• Seamless integration with our MiND app.
• 8 digital inputs include USB (hi-res audio), SPDIF (2), Optical (2), Qualcomm aptX audio for Bluetooth®, WiFi and Ethernet.
• OLED type screen which provides more detailed information.
• Simple MiND setup via on-board software menu.
• Moving magnet phono preamplifier input.
• Analog inputs are configurable to “pass-through” mode, which bypasses the gain stage to accommodate components like a home-theater processor, whose own volume control is used.

For MOON ACE equipped with MiND 2:

• AirPlay, TIDAL Connect, Spotify Connect compatible
• ROON Ready device
• Tidal Masters, Deezer Hi-Fi and Qobuz Sublime+ Music Services
• MQA decoding
• Multi-room synchronized playback

Specifications
Output Power at 8Ω
50 W per channel
Input Sensitivity
370 mV - 3.0 V RMS
Input Impedance
22,1 kΩ
Gain
37 dB
Signal-to-noise Ratio
100 dB @ full power
Frequency response (full range)
10 Hz - 80 kHz +0/-3 dB
Crosstalk
-100 dB
THD (20Hz - 20kHz @ 1 W / 50 W)
0.02 % / 0.02 %
Intermodulation distortion
0.005%
PCM Bit-depth range / sampling rates
16 - 32 bits / 44.1 - 384 kHz
DSD sample rates
DSD64, DSD128 & DSD256
Shipping weight
24 lb / 11 kg
Dimensions (width x height x depth)
16.9 x 3.5 x 14.4 in
42.9 x 8.9 x 36.6 cm
