PM6007

INTEGRATED AMPLIFIER WITH DIGITAL CONNECTIVITY

Your next step into Marantz HiFi

Featuring an upgraded, high-quality DAC, digital inputs and a newly revamped built-in phono equalizer, the Marantz PM6007 integrated amplifier features ample connectivity and creates a realistic listening experience for the most musical sound.

Current Feedback Amplifier

The Current Feedback Amplifier technology provides wide-bandwidth and high-speed sound reproduction. In combination with the high current power supply, the PM6007's amplifier holds a large energy reserve to easily drive even the most demanding speakers. An advanced thermal compensation avoids memory distortion for clean amplification under any circumstances.

Reference Quality D/A Conversion For Digital Input

The PM6007 features a new Hi-Res D/A conversion. It is equipped with a reference class D/A converter, which provides up to 192-kHz/24-bit resolution for optimum fidelity with your Hi-Res audio file types.

High Current Power Supply

The power supply supports high current, high speed Schottky Barrier Diodes and high current storage capacitors fed by a Toroidal Transformer that together provide wide dynamic range and low impedance drive capability

Toroidal Transformer

A Toroidal Transformer has several advantages over a normal EI core transformer. The highly efficient design delivers more power compared to the same size EI core transformer. In addition, the shape of the Toroidal Transformer delivers low electromagnetic radiation and mechanical vibration for better sound quality.

Marantz PM6007 Specs
Amplifier
Number of Channels    2
Power Output    45 W per Channel @ 8 Ohms RMS
60 W per Channel @ 4 Ohms RMS
50 mW / 32 Ohms (Headphone)
Frequency Response    10 Hz to 70 kHz
Signal to Noise Ratio    Phono (MM): 83 dB
High Level: 102 dB (2 V Input)
Total Harmonic Distortion (THD)    0.008% (20 Hz to 20 kHz kHz, 8 Ohms, Both Channels Driven)
Damping Factor    100 (8 Ohms, 40 Hz to 20 kHz)
Speaker Impedance    A or B or Bi-Wiring: 4 to 16 Ohms
A and B: 8 to 16 Ohms
Tone Control    Bass (50 Hz): ±10 dB
Treble (15 kHz): ±10 dB
Digital Input    Digital Coaxial: 0.5 Vp-p
Optical: ≥-27 dBm
Connectors
Input    4 x Stereo RCA
1 x Stereo RCA Phono (with Ground Screw)
2 x Optical TOSLINK
1 x RCA Digital Coaxial
Output    1 x RCA Subwoofer
1 x Stereo RCA
1 x 1/4" / 6.35 mm Headphone (Front)
Speaker Connectors    4 x Binding Post Pairs (L/R, A/B)
Other Connectors    1 x RCA Remote In
1 x RCA Remote Out
1 x 1/8" / 3.5 mm IR Flasher In
Input Sensitivity and Impedance    Phono (MM): 2.2 mV / 47 Kilohms
Other Inputs: 200 mV / 20 Kilohms
Output Voltage    Subwoofer: 2.8 V (200 mV Input, Max Volume)
RIAA Equalization Deviation    ±1 dB (20 Hz to 20 kHz)
Output Bandwidth    10 Hz to 50 kHz (8 Ohms, 0.06% THD)
Frequency Response    CD: 10 Hz to 70 kHz, +0, -1 dB (1 W, 8 Ohms)
Input Level    Phono, Max: 100 mV
Physical Specifications
Construction Material    Front Panel: Metal
Operating Temperature    41 to 95°F / 5 to 35°C
Power Requirements    240 VAC, 50/60 Hz
Power Consumption    Operational: 155 W
Standby: 0.3 W
Dimensions (W x H x D)    17.3 x 4.1 x 14.5" / 43.9 x 10.4 x 36.8 cm
Weight    16.7 lb / 7.6 kg
Packaging Info
Package Weight    22.6 lb
Box Dimensions (LxWxH)    20 x 18.8 x 7"
