R-120SW

SPUN COPPER IMG WOOFER
Injection Molded Graphite (IMG) woofers are exceptionally light while being extremely rigid – providing remarkable low frequency response, with minimal cone breakup and distortion.

ALL-DIGITAL AMPLIFIER
The built-in, all-digital amplifier delivers ample power with high efficiency and true-to-source accuracy in reproduction, ensuring maximum efficiency for maximum output, detail, and power.

FRONT-FIRING DRIVER
The high-performance driver provides deep bass and room placement flexibility.

LOW PASS CROSSOVER AND PHASE CONTROL
Ensures the subwoofer’s low-frequency tones blend with other Klipsch speakers and establish the ideal level of bass for your room.

LINE/LFE INPUTS
Ensures compatibility with home theater receivers.

MDF CABINET WITH SCRATCH-RESISTANT, TEXTURED WOOD GRAIN VINYL
Stylish aesthetic with absolute durability that results in a seamless integration into any décor.

FRONT-MOUNTED LED POWER INDICATOR
Indicates when the system is on or off.

LOW PROFILE GRILLE
Adds a refined look that is acoustically transparent.

SPECIFICATION:
FREQUENCY RESPONSE 29Hz - 120Hz +/- 3dB
MAXIMUM ACOUSTIC OUTPUT 116 dB
AMPLIFIER All Digital
AMPLIFIER POWER (CONT/PEAK) 200W/400W
AMPLIFIER FEATURES Volume, Low-pass, 0/180 phase, Auto Power On
DRIVER COMPONENTS 12” high excursion spun-copper IMG woofer
ENCLOSURE MATERIAL MDF
ENCLOSURE TYPE Bass-Reflex via rear-firing port
INPUTS Line level/LFE RCA jacks
HEIGHT 16.5” (419 mm)
WIDTH 14” (356 mm)
DEPTH 19.2” ( 488mm)
WEIGHT 31 lbs (14.1 kg)
FINISHES Black Textured Wood Grain Vinyl
BUILT FROM 2018
