AXA25

INTEGRATED AMPLIFIER

Offering 25 watts of power per channel in a great value package, the AXA25 features a 3.5mm aux input on the front for smartphones and four analogue inputs on the back panel for connecting all your sources.

整合放大器

AXA25 是一個極好的超值套裝，其每個頻道的功率為 25 瓦特，且在前端配備一個用於智慧手機的 3.5 毫米音頻輸入接口，以及在後面板上有四個類比輸入接口，以連接所有訊號源。

Need Extended Warranty? Click Here:
https://www.stylelaser.com.my/product/style-extended-warranty/

POWER OUTPUT

25 Watts (into 8 Ohms)

THD (UNWEIGHTED)

<0.015% @ 1kHz, 80% of rated power <0.15% 20Hz – 20kHz, 80% of rated power <0.1% 20Hz – 20kHz @ 10W

FREQUENCY RESPONSE (-3DB)

(-3dB) 10Hz - 30kHz

S/N RATIO (REF 1W)

>82dB (unweighted)

INPUT IMPEDANCES

32k ohms

POWER AMP DAMPING FACTOR

> 100

MAX. POWER CONSUMPTION

180W

BASS/TREBLE CONTROLS

Shelving, ultimate boost/cut +/- 5.5dB @ 20Hz and 20kHz

STANDBY POWER CONSUMPTION

<0.5W

INPUTS

4x RCA, 1 x 3.5mm Aux input (front panel)

OUTPUTS

Speakers, Rec Out, USB 5V power

DIMENSIONS (HXWXD)

83 x 430 x 340mm (3.3 x 16.9 x 13.4”)

WEIGHT

5.1kg (11.2lbs)
